A new generation of pocket chargers：DC 240W high power / max 10A output with USB C 140W/5A max output,meet your multi-scenario high power for Lipo battery charger needs.
Truly intelligent charger: Support APP connection, fully intelligent battery management, one-click view of battery parameters and charging status.
IPS screen：Low power consumption, 1.5 inch IPS screen, automatic brightness adjustment, viewing angle 178°, clear and clear display, even in difficult environments or angles, even in strong sunlight.
Powerful cooling system：Advanced artistic cooling air duct, active design of the cross flow cooling air duct, initiator ball bearing fan, with precisely engineered aluminium alloy fins and hi-tech silicon heat conducting pad, construction of a highly efficient heat dissipation system.
Universal charger: Supports charging and discharging for most batteries, including: LiFe, LiPo, LiHv (4.35V~4.50V) 1-6S/Pb 1-12S/NiMH 1-16S, etc.
Specifications
- Maximum Input Current: DC 10A,USB-C 5A
- Input voltage range: DC 5-30V, USB-C 5-28V
- Output Voltage Range: DC 3.0~30V
- Charging Current: 0.5~10.0A
- Maximum charging power: 240W/10A,140W/5A
- Maximum Discharge Power: USB-C 100W/5A
- Support battery type and series: LiFe,LiPo,LiHv(4.35V~4.50V)1-6S/Pb 1-12S/NiMH 1-16S
- Balance Current: 0.8A/Cell Max
- Operating Temperature: 0~40℃ Storage Temperature: -20~60
- Abnormal battery voltage alarm: Support
- Alarm for string number setting error: Support
- Dimension: 72.5×60×26.6mm
- Weight: 85g(±10%)
PRODUCT MANUAL
Gastos estimados de envío
ISDT 608PD LiPO charger
My first lipo charger. Small, compact and after looking through the manual charged my 4s batteries perfectly. Make sure you read the manual carefully, there’s a few options to choose for the different types of batteries . The balancing port/insert was a bit confusing, but only because I’m a bit of a noob. You can charge with a type C usb, there’s a DC input and you can discharge your batteries with this device also. It’s great to use and cheap as well.
